PM891K01 3BSE053241R1 Redundant controller module

Basic Parameters

• Module Type: High-end redundant main controller of the AC 800M series
• Processor: Equipped with a high-performance 32-bit processor with fast operation speed, supporting large-scale parallel processing and complex control algorithms
• Memory Configuration:
  • Program Memory (RAM): Typical 256MB, supporting the operation of large-capacity control programs
  • Data Storage (Flash): Typical 1GB, capable of persistently storing programs, configuration files, and massive process data
• Communication Interfaces:
  • 2 Gigabit Ethernet interfaces (10/100/1000 Mbps), supporting protocols such as TCP/IP, Modbus TCP, and OPC UA, meeting the requirements of high-speed data transmission and redundant communication
  • 1 ModuleBus interface for connecting S800 I/O series modules, enabling high-speed acquisition of on-site signals and issuance of control commands
  • Supports CEX bus redundancy expansion, allowing connection to remote I/O stations and other controllers
• Redundancy Function: Supports full-system redundant configuration (controllers, power supplies, communication links, I/O modules) with an active-standby switchover time ≤ 10ms, ensuring uninterrupted operation of critical production processes
• Operating Voltage: 24V DC (±10%)
• Power Consumption: Typical 18W, maximum 25W
• Operating Temperature Range: -25°C to +70°C (wide-temperature design, adapting to harsh industrial environments)
• Storage Temperature Range: -40°C to +85°C

Functional Features

1. Superior Computing and Expansion Capability: The high-performance processor combined with large-capacity memory can support tens of thousands of I/O points, easily handling complex multivariable control, model predictive control (MPC), and batch control tasks, meeting the control needs of large-scale integrated plants.
2. Comprehensive Redundancy Design: Controllers, power supplies, communication networks, and I/O links all support redundant configuration. Combined with an intelligent fault detection mechanism, it achieves millisecond-level non-disturbance switching, with system availability reaching over 99.999%, suitable for critical processes that do not allow any downtime.
3. Advanced Security and Certifications: Certified by ISA Secure, SIL 3, etc., it supports the integrated design of Safety Instrumented Systems (SIS) and Process Control Systems (PCS), meeting the strict safety requirements of industries such as chemical engineering and nuclear power.
4. Flexible Programming and Integration: Compatible with ABB 800xA Control Builder programming environment, supporting IEC 61131-3 standard languages and object-oriented programming, and providing a rich library of industry-specific function blocks (e.g., oil and gas, electric power, water treatment); it can seamlessly interface with third-party systems (such as MES, ERP) to achieve enterprise-level data intercommunication.
5. Intelligent Diagnostics and Maintenance: Equipped with real-time health monitoring, fault early warning, and remote diagnostic functions, supporting online programming, firmware upgrades, and module hot swapping, significantly reducing maintenance costs and downtime.
6. Industrial-grade Anti-interference Capability: Adopts enhanced electromagnetic compatibility (EMC) design, passing multiple international industrial certifications, and can operate stably in harsh environments such as strong electromagnetic interference, high temperature, and high humidity.

Application Fields

• Mainly used for core control in large-scale industrial automation systems, such as ultra-large-scale control scenarios including integrated petrochemical complexes, large nuclear power plants, extra-large thermal power plants, and urban rail transit networks.
• Particularly suitable for fields with extremely high requirements for system reliability, computing capability, and safety level, such as hazardous chemical process control, nuclear reactor safety monitoring, and large power grid dispatching, providing a stable, accurate, and safe control core for complex industrial processes.

The company has multiple main brands, and if you have other brand requirements, you can also send them to customer service for inquiry.
