PM866K01 3BSE050198R1 AC 800M series controller module

PM866K01 (order number: 3BSE050198R1) is a high-performance controller module in ABB's AC 800M series. Here is its detailed information:

Basic Parameters
- Processor Type: Dual-core ARM Cortex-A9, with a main frequency of 800MHz.
- Memory: 4MB eMMC memory, 2GB RAM.
- Communication Interfaces: 2 Ethernet ports, 2 serial ports (RS232/RS485), 1 PROFINET DPU interface.
- Power Supply: 24V DC.
- Operating Temperature Range: -20°C to +60°C.
- Storage Temperature Range: -40°C to +85°C.
- Installation Method: DIN rail mounting.
- Operating Humidity: 5% to 85%.
Functional Features
- High Performance: Equipped with a dual-core ARM Cortex-A9 processor, ensuring fast response and reliable operation.
- High Reliability: Suitable for harsh industrial environments, featuring high reliability and flexibility.
- Modular Design: Facilitates expansion and maintenance, and has good compatibility with other ABB control system products.
- Rich Communication Interfaces: Supports multiple communication protocols such as Ethernet, Modbus TCP/IP, and PROFIBUS.
Application Fields
- This module is mainly used for process control, data acquisition, fault diagnosis, etc., in industrial automation systems. It can execute complex control tasks and provide real-time response and deterministic performance.
- It can be applied in various industries such as electric power, petrochemicals, metallurgy, papermaking, manufacturing, mining, transportation, and environmental monitoring.
