X-AI3201 985210213 high-density analog input module

X-AI3201 985210213 is a high-density analog input module designed for industrial automation control systems, focusing on large-scale, high-precision acquisition of field analog signals (e.g., pressure, temperature, flow). It is characterized by multi-channel integration, strong anti-interference performance, and wide environmental adaptability, making it a core component for signal collection in process industries and manufacturing. Below is its integrated detailed information:

1. Core Technical & Electrical Parameters

Parameter Category	Specific Details
Channel Configuration & Signal Compatibility	- Total analog input channels: 32 independent isolated channels, supporting two mainstream signal types.1. Current signals: 4–20mA DC (two-wire/three-wire transmitters), 0–20mA DC.2. Voltage signals: 0–10V DC, 1–5V DC, ±5V DC, ±10V DC (for sensor signals like thermocouples, RTDs after conditioning).- ADC resolution: 16-bit; ensures high-precision conversion of weak analog signals.
Accuracy & Signal Performance	- Measurement accuracy: ±0.1% full scale (FS) at 25°C; ±0.2% FS over the operating temperature range (-40°C to 70°C).- Temperature drift: ±0.001% FS/°C; minimizes accuracy loss caused by ambient temperature fluctuations in control cabinets.- Input impedance: ≤250Ω (current signals), ≥100kΩ (voltage signals); avoids affecting the output accuracy of field transmitters.- Sampling rate: 10Hz per channel (configurable up to 50Hz); balances real-time performance and power consumption.
Isolation & Anti-Interference	- Channel-to-channel isolation: ≥1500V DC (1 minute); prevents cross-interference between multi-channel signals.- Module-to-backplane isolation: ≥2500V DC (1 minute); suppresses ground loops and electromagnetic interference (EMI) from industrial sites (e.g., motors, inverters).- Built-in functions: Digital filtering (configurable cutoff frequency: 0.1Hz–10Hz), signal linearization, and offset calibration; optimizes unstable field signals.
