HIMA F3 DIO 8/8 01 digital input/output module

HIMA F3 DIO 8/8 01 is a safety-related digital input/output module under HIMA's HIMatrix series, which is widely used in industrial automation scenarios requiring stable signal collection and control. It has the characteristics of compact structure, reliable performance and complete safety protection functions. The detailed information is sorted out as follows:

Core Electrical and Physical Parameters

Parameter Category	Specific Details
Voltage and Power Consumption	The operating voltage is 24V DC, with a voltage tolerance range of -15% to +20%. The power consumption is 120mA under 5V DC and 200mA under 24V DC. When running at full load, the maximum current input can reach 8A, and the no-load current is about 0.4A under 24V DC.
I/O Channel Configuration	It is equipped with 8 non-galvanically separated digital input channels and 8 digital output channels (DO+). In addition, there are 2 additional DO- digital output channels and 2 pulse output channels. Among them, the digital output terminals DO4+, DO8+, DO4- and DO8- can also be connected in two poles, which improves the flexibility of wiring.
Physical and Environmental Indicators	The protection level is IP20, which can prevent dust and light water splashes and is suitable for general industrial control cabinets. There are slight differences in size records from different suppliers. A mainstream specification is 152mm (width) × 114mm (height) × 66mm (depth), and the weight is about 1kg. The operating temperature range is mostly recorded as 0°C - 60°C, and the storage temperature can reach -40°C - 85°C.
