EMERSON A6110 dual-channel shaft relative vibration monitor belonging to the AMS 6500 series

1. Core Technical Parameters

   Parameter Category	Specific Details
   Input Parameters	It has two input channels, supporting independent or combined monitoring modes, and is compatible with eddy current and differential sensor inputs. The input resistance is greater than 100 kΩ, the input voltage range is 0 to -22 VDC, and the sensor power supply supports 0 - 8000 mV. The lower cut-off frequency of the input frequency is 1 or 5 Hz, and the upper cut-off frequency is adjustable from 50 Hz to 2000 Hz. It is well-matched with Emerson PR6422/PR6423/PR6424/PR6425 displacement sensors and CON 011/91, 021/91, 041/91 drivers.
   Output Parameters	It is equipped with front and rear buffer and proportional output interfaces, providing 0/4 - 20 mA current output and 0 - 10 V voltage output, which is convenient for connecting with subsequent control systems and display instruments for data transmission and control execution.
   Physical & Power Specifications	It adopts a 3U size and 1 - slot plug-in design. The typical size is 120 mm × 80 mm × 70 mm. The power supply is 24V DC, and the power consumption is about 10W. Compared with traditional equipment, it can reduce the cabinet space demand by half.



2.

3.

4.

5. The company has multiple main brands, and if you have other brand requirements, you can also send them to customer service for inquiry.
