PPD512 A10-454000 specialized Power Protection & Detection Module

PPD512 A10-454000 is a specialized Power Protection & Detection Module developed by ABB, primarily designed for medium-to-high voltage power electronic systems. It focuses on real-time fault detection, power parameter monitoring, and coordinated protection with upper-level control units (e.g., ABB’s PPC series control units), acting as a "safety barrier" for critical equipment such as industrial drives, inverters, and grid-connected converters. Its core value lies in fast fault response and accurate protection logic, ensuring the safety of power semiconductors (IGBTs/IGCTs) and the entire system. The detailed information is as follows:

1. Basic Product Overview

2. Key Electrical & Hardware Specifications

2.1 Power Supply Requirements

• Input Voltage: 24VDC ±15% (for internal detection circuits and logic control; supports dual redundant input (optional) to avoid protection failure due to single power supply outage).
• Power Consumption: Typical 8W (normal monitoring state), maximum 15W (fault detection and signal transmission state).
• Isolation Performance:
  • Between high-voltage signal input terminals and low-voltage control terminals: ≥4000V AC (1 minute, IEC 60664-1 standard) – critical for isolating medium-voltage power circuits from low-voltage control systems and ensuring operator safety.
  • Between power supply terminals and signal terminals: ≥2500V AC (1 minute), preventing electrical interference from affecting detection accuracy.

2.2 Detection Capabilities & Parameters

• Overcurrent Detection:
  • Input signal type: AC current (via current transformers (CTs) with ratio 1000:5A or 2000:5A, compatible with most industrial CT specifications);
  • Detection range: 0–2000A (continuous current), 0–10000A (peak surge current);
  • Accuracy: ±2% (within 10%–100% of full scale);
  • Response time: ≤50μs (for overcurrent faults exceeding 150% of rated current, ensuring fast shutdown of power semiconductors).
• Overvoltage/Undervoltage Detection:
  • Input signal type: DC bus voltage (direct sampling) or AC grid voltage (via voltage transformers (VTs) with ratio 1000:100V);
  • Detection range (DC): 0–3000V (for medium-voltage drive DC buses), (AC): 0–1000V (rms, for 380V/690V/10kV grid systems);
  • Accuracy: ±1.5% (within 20%–100% of full scale);
  • Threshold setting: User-configurable via ABB’s dedicated configuration software (e.g., Protection Suite) to match system rated voltage.
