F3 DIO 20/8 02 digital input/output module

HIMA F3 DIO 20/8 02 is a digital input/output module under the HIMATRIX series, specifically designed for safety-related control scenarios. It is often used to expand I/O capacity in industrial automation systems. Below is its detailed information:

1. Basic Core Information

Product PositioningThis module is a remote I/O module compatible with HIMATRIX series safety controllers. It cannot run user programs independently and must be used with HIMax or HIMatrix controllers. Its safety level reaches SIL 3/PL e (Cat.4), which can meet strict safety control requirements in industrial scenarios.
Mechanical StructureIt adopts a compact metal housing design with strong mechanical properties and high reliability. It supports DIN rail mounting, making it suitable for installation in industrial control cabinets with limited space. The housing has an IP20 protection rating, which can prevent accidental contact and dust intrusion.

2. Core Technical Parameters

I/O ConfigurationEquipped with 20 isolated digital input channels and 8 isolated digital output channels. The inputs are compatible with TTL levels. The outputs can sink or source current; the maximum current of conventional models reaches 250mA. Under specific conditions:
- Outputs 1–3 and 5–7 can carry 0.5A per channel at the maximum ambient temperature.
- Outputs 4 and 8 can carry 1A; when the ambient temperature does not exceed 50°C, outputs 4 and 8 can even carry 2A.The input voltage range is 0–30VDC (configurable for positive or negative logic), with a maximum input frequency of 10kHz. The output voltage range is 5–30VDC.
