VE4002S1T2B5 control module

VE4002S1T2B5 is an industrial control module under Emerson's DeltaV series.

Core Basic Parameters

Parameter Category	Specific Details
Core Electrical Specifications	It adopts a 32-channel design and is applicable to 24V DC high-side application scenarios. Each channel supports 24V DC and 100mA; the local bus power supply is 12V DC and 150mA, and the centralized field power supply of the module can reach 24V DC and 3.2A. There is also information showing that its rated voltage can reach 550V and the output frequency is 55kHz.
Environmental Adaptability	The operating temperature range is -40°C to +70°C, which can adapt to harsh industrial temperature environments; it has shock resistance performance of 10g half-sine wave for 11ms. The relative humidity adaptation range is 5%-95% (non-condensing), and individual suppliers indicate that its protection level reaches IP65.
Physical Indicators	Different sources have great differences in size and weight data. One of the mainstream specifications is 85mm×230mm×145mm and weighs 0.5kg; there are also data showing that its size is 100mm×50mm×25mm, and the weight is only 90 grams. The specific parameters need to be subject to the factory delivery standards.
Communication & Other Features	It supports communication protocols such as Modbus RTU and Foundation Fieldbus H1, and is also equipped with communication interfaces like RS485 and Ethernet to realize data interaction with the overall industrial control system. Its power consumption is ≤3W, featuring low energy consumption, and it has passed certifications such as CE and ROHS.
