A6500-UM universal measurement card

EMERSON A6500 - UM is a universal measurement card that serves as a key component of the AMS 6500 ATG machinery protection system. It is widely used in industrial equipment monitoring scenarios due to its strong compatibility with various sensors and diverse measurement capabilities. The detailed information is as follows:

Core Technical Parameters

Parameter Category	Specific Details
Input Parameters	It is equipped with 2 sensor input channels and 5 digital inputs. The input channels can be used independently or in combination. It is compatible with multiple sensors like eddy current, piezoelectric, seismic, LF, Hall effect, and LVDT (used with A6500 - LC). The input signal range covers 0 - +10 VDC or 4 - 20 mA, and the typical measurement accuracy can reach ±0.1%.
Output Parameters	There are 6 digital outputs, and it supports 0/4 - 20 mA analog output. These analog outputs have a common ground and are electrically isolated from the system power supply. At the same time, it can transmit signals through the RS485 digital signal mode.
Communication Performance	The measurement signals are transmitted to the A6500 - CC communication card via the internal RS485 bus, and converted into Modbus RTU and Modbus TCP/IP protocols for transmission to the host or analysis system. The matching communication card also has a USB interface on the panel to connect to computers for configuration and data viewing.
Physical & Power Specifications	It adopts a 3U - size, 1 - slot plug - in module design. There are slight differences in size and weight among different batches. Some data shows its size is 144×89×35 mm and weight is about 0.5 kg, while another source indicates a weight of 200g excluding packaging. It generally uses a 24VDC power supply.
