PPD113B03-26-100110 3BHE023584R2634 excitation control module

PPD113B03-26-100110 (with 3BHE023584R2634 as its order number) is an excitation control module launched by ABB, mainly designed for controlling the excitation system of generators. It is suitable for scenarios such as power plants where high requirements are placed on the control accuracy and reliability of excitation systems. The detailed information is as follows:

1. Basic Overview

Brand: ABB
Installation Method: Control room installation
Structural Form: Modular design
Weight: Approximately 2.59 kg
Dimensions: Length 145 mm × Width 100 mm × Height 450 mm
Operating Voltage: 24VDC
Operating Temperature: 0°C to 70°C
Operating Humidity: 5% to 95% relative humidity (non-condensing)

2. Functional Features

Precise Regulation: Adopts advanced digital control technology to provide accurate voltage regulation, ensuring the stability of the generator’s output voltage.
Rapid Response: Features a fast response time, enabling timely feedback to changes in the excitation system’s status and maintaining stable system operation.
High Safety: Equipped with real-time monitoring functionality, it can promptly detect abnormal conditions in the system and quickly take protective measures to prevent the expansion of faults.
Strong Expandability: Supports function expansion and customization according to actual application requirements, facilitating integration with other equipment or systems.
Convenient Programming: Integrates the LogicsManager™ programmable logic function, offering programming flexibility and typically eliminating the need for additional PLC control.

3. Interface Capabilities

Rich Communication Interfaces: Equipped with multiple communication interfaces (such as Ethernet and serial communication interfaces), facilitating data interaction with other equipment and systems.

4. Application Fields

Power Generation Industry: Can be used to monitor equipment such as generators, steam turbines, and speed governors, ensuring the stable operation of power generation systems.
Oil and Gas Industry: Provides control for the excitation systems of motor equipment involved in oil and gas production and processing scenarios.
Manufacturing Industry: Applied to various industrial motor equipment in the manufacturing sector to achieve precise control of excitation current, thereby ensuring the stability of production processes.
