3500/33 149986-01 16 channel relay control module

1. Basic Information

• Brand: Bently Nevada
• Model: 3500/33
• Part Number: 149986-01
• Product Type: Relay Control Module
• Number of Channels: 16
• Supply Voltage: 24 VDC

2. Physical Characteristics

• Dimensions (Main Module): 241 mm × 24.4 mm × 242 mm (9.50 in × 0.96 in × 9.52 in)
• Weight (Main Module): 0.7 kg (1.6 lb)
• Dimensions (I/O Module): 241 mm × 24.4 mm × 99.1 mm (9.50 in × 0.96 in × 3.90 in)
• Weight (I/O Module): 0.4 kg (1.0 lb)
• Installation Method: Can be installed in any slot to the right of the Transient Data Interface (TDI) module in the 3500 system rack. It occupies 1 full-height front slot (for the main module) and 1 full-height rear slot (for the I/O module).

3. Electrical Characteristics

• Relay Type: Single-Pole Double-Throw (SPDT)
• Relay Environmental Sealing: Epoxy Sealed
• Relay Arc Suppressor: Standard 250 V RMS Installation
• Relay Contact Life: 10,000 Cycles
• Contact Ratings (Standard System – DC Resistive Load):
  • Maximum Switching Current: 3 A
  • Maximum Switching Power: 70 W at 24 VDC, 10 W at 48 VDC, 9 W at 60 VDC
  • Maximum Switching Voltage: 125 VDC
• Contact Ratings (Standard System – AC Resistive Load):
  • Maximum Switching Current: 3 A
  • Maximum Switching Power: 1200 VA
  • Maximum Switching Voltage: 250 VAC
