FBM230 P0926GU field device system integration module

The FBM230 P0926GU is a field device system integration module designed by Foxboro for its I/A Series Distributed Control System (DCS). Below is its detailed information:

1. Basic Information

Product Model: FBM230 P0926GU
Manufacturer: Foxboro (under Schneider Electric)
Product Type: Field device system integration module

2. Technical Specifications

Supported Protocols: FOUNDATION fieldbus H1, HART
Number of Channels: 4 channels (for FOUNDATION fieldbus); multi-channel (for HART, depending on configuration)
Supply Voltage: 24V DC (typical value)
Power Consumption: Typical value depends on load
Operating Temperature: -40°C to +70°C
Storage Temperature: -40°C to +85°C
Relative Humidity: 5% to 95% (non-condensing)
Installation Method: I/A Series cabinet mounting
Electrical Isolation: Supported

3. Key Features & Advantages

Multi-Protocol Compatibility: Integrates with various types of intelligent field devices, providing high flexibility and selectivity for users while reducing the complexity of system integration.
High Reliability: Features a wide operating temperature range and high humidity tolerance, ensuring stable and reliable operation under various harsh conditions.
Enhanced Device Diagnostics: Supports comprehensive diagnostics for connected intelligent field devices, including device status, parameter configuration, and fault information. This helps users detect and resolve potential issues in a timely manner, improving device availability and maintenance efficiency.
Simplified On-Site Wiring: By supporting fieldbus technology, it significantly reduces the quantity and complexity of on-site wiring, lowering installation costs and maintenance workload.
