FPS400-24 P0922YU industrial-grade power supply module

The FPS400-24 P0922YU is an industrial-grade power supply module launched by Foxboro, tailor-made for the brand’s I/A Series Distributed Control System (DCS). It provides stable power for industrial automation control systems and is widely used in various harsh industrial scenarios. Below is its detailed information:

1. Core Electrical Parameters

Parameter	Details
Rated Output Specification	Output voltage: 24V DC; rated power: 400W, capable of meeting the simultaneous power supply needs of multiple modules in a DCS.
Input Power Supply	Supports wide-range dual-power redundant input of DC9–36V; typically connected to a 24V DC power supply in practical applications, adapting to diverse power supply environments in industrial fields.
Power Protection Performance	Features 1500V DC power isolation to effectively prevent interference between different circuits; also equipped with reverse polarity protection for the power supply to avoid module damage due to incorrect wiring.
Power Consumption	Operating power consumption is less than 4W, ensuring stable power supply while reducing energy consumption, meeting the energy-saving needs of industrial equipment.

2. Key Functional Features

Multiple Safety Protections:In addition to power reverse polarity protection and isolation protection, its electrical interface also has 4000V lightning protection, 1.5A overcurrent protection, and 600W surge protection. These functions can resist common on-site incidents such as power grid fluctuations and induced lightning strikes. It also has passed EMC testing and certification, with excellent anti-interference performance.
Fault Alarm Mechanism:Equipped with 6 dual-color LED status indicators to intuitively display the power supply’s operating status and fault conditions. It also has a power fault relay output alarm function; the alarm contact supports a DC48V/1A load, allowing staff to detect and handle power anomalies in a timely manner.
Easy Installation & Protection:Adopts an IP30 protection rating design, paired with a corrugated aluminum reinforced housing to resist dust, light oil pollution, and other hazards. The installation method is standard industrial 35mm DIN rail mounting, adapting to the standardized installation layout inside industrial on-site control cabinets for easy disassembly and maintenance.
