HIMA F7133 4-channel power distribution module

HIMA F7133 is a 4-channel power distribution module tailored for HIMA safety systems. It is mainly responsible for stably distributing power to industrial on-site I/O modules, sensors and other equipment, and integrates fuse protection and fault indication functions. It is widely used in safety-critical industrial fields due to its compact structure and high reliability. The detailed information is as follows:

Core Technical Parameters

Parameter Category	Specific Details
Power Supply Parameters	The operating voltage is 24V DC, and the operating current is 60mA. There are also versions with an input voltage range of 110 - 240V AC and an output voltage of 24V DC in the market to adapt to different power supply scenarios of industrial sites.
Channel & Fuse Configuration	It has 4 power distribution channels, and each channel is equipped with a micro slow - blow fuse. The maximum current that each fuse can withstand is 4A. When the circuit current is abnormal, the fuse will trip quickly to protect the subsequent connected equipment. Moreover, after the fuse trips, the residual voltage and residual current of the channel can be reduced to 0V and 0mA respectively, avoiding potential safety hazards caused by residual electricity.
Relay Performance	The switching time of the relay is about 100ms, and the continuous load capacity of the relay contact is 30V/4A. It can match resistive, inductive and capacitive loads, and the switching frequency can reach up to 1kHz, which can meet the power supply switching needs of most industrial equipment.
Physical & Environmental Indicators	Its weight is 0.25kg, and the overall size is about 20.7×14.7×6.7cm. The space required for installation is 4TE. It adopts a DIN rail mounting method, which is convenient for integration into the standard industrial control cabinet. The protection level is IP20, suitable for cabinet - mounted use. The operating temperature range of mainstream models is -10°C to 60°C, and some extended versions can withstand the environment of -20°C to 60°C. The storage temperature range is -40°C to 85°C, which can adapt to the temperature changes of most industrial sites.
