3BHE039724R0C3D PPD513AOC-100440 high-performance industrial automation control module
The 3BHE039724R0C3D PPD513AOC-100440 is a high-performance industrial automation control module manufactured by ABB. It is a core power unit module of the ACS800 series medium-voltage frequency converters and a standard component of the D513 power cabinet. The detailed information is as follows:
- Product Type: Industrial automation control module
- Input Voltage: Multiple specifications available, including 24V DC and 120V AC
- Dimensions: Length 100mm × Width 70mm × Height 35mm
- Processing Speed: 400MHz
- Control Accuracy: ±0.5%
- Power Conversion: Adopts an IGBT three-level NPC (Neutral Point Clamped) topology, which can convert the input three-phase AC power of 3.3kV/6kV/6.6kV (±10%) into output voltage of the same level. The output frequency range is adjustable from 0.1Hz to 120Hz, with an overload capacity of 150% rated current for 60 seconds and 200% rated current for 3 seconds.
- Control Modes:
- Equipped with open-loop V/f control mode, suitable for simple speed regulation scenarios such as fans and pumps.
- Supports closed-loop vector control, and can realize sensorless vector control (DTC) with a dynamic response time of less than 5ms, applicable to high-precision load scenarios such as hoists and extruders.
- Communication Interfaces: Supports multiple communication protocols including Ethernet/IP, Modbus RTU, Profibus DP, and Profinet. An optional dual Ethernet interface is available to support ring network redundancy, with a communication interruption recovery time of less than 200ms.
- Safety Protection:
- Has overcurrent, overvoltage, and undervoltage protection functions; automatically cuts off the output and alarms when a fault occurs.
- The response time of ground fault detection is less than 10ms.
- Supports flying start function, which can quickly synchronize and control the motor when it is rotating freely, avoiding mechanical impact.
- Modular Design: The module features small size and light weight, facilitating installation, maintenance, and expansion.
- High Reliability: Adopts industrial-grade design standards, capable of adapting to harsh industrial environments and ensuring long-term stable operation of equipment.
- Low-Power Design: Optimized for energy consumption, effectively reducing overall operating costs.
- Industrial Automation: Can be used for the control of various equipment such as robots, machine tools, packaging machinery, and printing machinery.
- Power Electronic Systems: Suitable for power electronic equipment such as LED lighting systems, voltage restorers, and drives.
- Energy Management: Applicable to scenarios such as wind turbines, micro-turbines, and light rail propulsion systems to support energy management.
- Process Control: Can be used for precise control of process variables in industries such as petrochemicals and metallurgy.
The company has multiple main brands, and if you have other brand requirements, you can also send them to customer service for inquiry.
